Martin 1400 mm Sliding table T12 + T27

From £7,500.00 + VAT

(£9,000.00 inc VAT)

Sliding Table with 1400 mm operating range, for cutting heavy mortising and counter profiles.

Call our sales team 0116 2893469
Payment Options
  • Finance Options Available
  • Payment on Account/Invoice
  • Credit/Debit Card
Payment Options

Sliding Table

The sliding table is the ideal partner irrespective of whether you profile larger cross-sections across the grain, cut counter profiles, or carry out tenoning and mortising tenoning work.

The sturdy table provides a large and safe support and can be turned in both directions by up to 45°, and even up to 65° in the case of the fence. As a result, diagonally cut workpieces, e.g. in special window construction, can also be securely clamped and processed.

The sliding table has a large travel of 1,400 mm, in order to enable the safe processing of large workpieces. Tools up to 350 mm ø can be safely used on a 40 mm arbor with the supplied mortising guard.

Left-hand table extension

If the sliding table is not required, it forms a perfect left-hand table extension, since the table can be lowered to machine table level. The guide beam can be easily moved to the rear and is thereby level with the front of the machine.

Mortising guard

If the mortising guard is used, the max. speed is limited to 4,500 rpm (or 4,800 rpm with infinitely variable rotational speed).

Feed support leg

If a feed support leg is required, it can only be mounted on the right of the spindle.
