Technical Specifications
MAKE
AG
VOLTAGE / PHASE
415V / 3ph
MODEL
4 Bag Multi Filter
Product features:
- Stainless Steel Quick release waste retaining straps
- Direct on line starter (Supply only)
- CE certified
- High filtration rate for fine dust, mdf
- Ideal for CNC machines
- 7.5kw / 10hp motor
- 4250 m3/hr
- 20m / sec
- 3200mm long, 900mm wide, 3300mm high
- 250mm inlet
Optional accessories:
AG 4 Bag multi dust extractor can be built to your specifications.
Made in Leicester, UK.
- Top enclosure
- Weather proof top enclosure
- Shaker unit
- Fully enclosed for noise reduction
