Technical Specifications
Length approx.
640 mm
Height approx.
490 mm
Drive motor output
0.9 kW
Supply voltage
230 V
Extraction port diameter thickness
52.5 mm
Max. cutting depth
2.8 mm
Number of planing blades
2
Max. planing width
330 mm
Working height max.
152 mm
Width/depth approx.
585 mm
Weight approx.
33 kg
Absorbed power drive motor
1,5 kW
Mains frequency
50 Hz
Feed speed
6 m/min
Type of Planing knife shaft
Strip planer blade shaft
Planing knife shaft speed
8500 min¯¹
Working height min.
6 mm
Max. cutting depth
2,8 mm
