Technical Specifications
Tersa
Tersa cutterblock: fast changing of the knives and small response time thanks to the TERSA knive system.
Spiral Infeed Roller
Spiral infeed roller guarantees an efficient feed motion of the wood and a good quality.
4 Sturdy Columns
The thicknesser is based on to 4 sturdy columns.
Frame
The frame is built on 6 mm steel plate and is carefully designed to maximise strength and rigidity, it’s made in a so called ‘box frame’ resulting in an extremely sturdy and torsion resistant base.
Motors and Transmission
The machine is equipped with 5.5kW (7.5HP) motor as standard with an option of a 7.5kW (10HP) motor. Standard tension of the motor is 400 volt. This machine is also available in single phase.
Up to 250mm
It is possible to work pieces of woord with a thickness up to 250 mm.
Friction Reduction Rolls
2 friction reduction rolls for easier processing of wet wood.
Comfort Pack
The comfort pack on the SD 510 consists out of 4 feeding speeds, digital read out of the height and an automatic star delta switch.
