Technical Specifications
Motor (V/kW)
400 / 3.7
feed speed (m/min)
7
Thicknessing height (mm)
225
Maximum thicknessing depth of cut (mm)
4.5
table size (mm)
600 x 740
Indexable inserts number
96
fence size (mm)
1,150 x 150
Dust port(s) Diameter (mm)
100 & 120
Cutterhead rotation (rpm)
5,500
maximum planing width (mm)
407
maximum depth of cut (mm)
3
number of knives
3 planer blades
planing table length (mm)
1,660
minimum thicknessing length (mm)
150
Fence tilt
45° / 90°
Weight (KG)
315
Features
Dual fold-out table to switch from planing to thicknessing in a matter of seconds, without removing the fence
Graded planing tables made from high-quality cast iron guarantee outstandingly smooth workpiece movement
Two-sided eccentric regulation for quick adjustment of the chip remover and hollow joint
The 3-knife shaft allows fast processing and top planing results
Large-sized planer fence made from aluminium, inclinable to 45°, precisely machined, stable in operation
Warp resistant one-piece machine casing for unfailing precision
Feed can be turned off
