Robland NX310 Pro II Combination Machine 1ph

£9,500.00 + VAT

(£11,400.00 inc VAT)

The Robland NX310 PRO Combination Machine comes with inward folding planer beds, a telescopic arm, scribe blade option (Not installed), and a multi-speed spindle.

  • OPTIONS FITTED TO THIS MACHINE –
  • 2500MM SLIDING TABLE
  • SPIRAL CUTTER BLOCK
  • ANALOGUE READOUTS ON THE THICKNESSER AND SOINDLE HEIGHTS
  • SINGLE PHASE
Call our sales team 0116 2893469
Payment Options
  • Finance Options Available
  • Payment on Account/Invoice
  • Credit/Debit Card
Payment Options

Technical Specifications

Scoring blade diameter
100 mm
Sliding tabke width
320 mm
Motor Power 1ph/3ph
3 HP / 5HP
Cutting depth at 45Ā°
55 mm
Cutting capacity of sliding saw
1650 mm
Thickness capacity
310mm
Overall length of surface tables
1400 mm
max. Diameter above table
180 mm
Spindle Speed
2900 / 4000 / 6000 / 7500 RPM
Stroke
165 x 140 x 85 mm
Table dimensions
1080 x 410 mm (Cast Iron)
Saw blade diameter with scoring saw
250 mm
cutting depth at 90Ā°
85 mm
Planer Block Diameter
70 mm
Number of knives
3
Spindle Diameter
30 mm
Usable length of spindle
140 mm
Mortise chuck capacity
0 – 16 mm
Saw Blade diameter
250 mm
Optional support wheel kit that lifts up the machine for easy manoeuvring. Robland Planer thicknesser NXSD 410
Optional Wheel System

With the wheel system, you can easily move your machine around your workshop.

Handwheel for thicknessing bed with optional analogue readout. Robland Planer thicknesser NXSD 410. Robland Planer Thicknesser NXSD
Hand wheel

The thicknesser height adjustment hand wheel with integrated mechanical read out offers even more comfort and precision.

HX TZ Fold away support table
Optional Fold Away Support Table

Cast Iron power feed “fold away” support table.

Optional Tersa

The 3-Knives Tersa cutter block offers you all the comfort and precision when changing the knives.

Spindle

Standard spindle diameter is 30 mm, the working length is 120 mm. The up-and-down stroke is 140 mm. (4 speeds)

HX 260 Jointer fence
Jointer Fence

The large, hard anodised, jointer fence makes edge planing easy. Thanks to its special swivel-support bracket, the fence sets at any angle without a gap between the fence and the table surface.

Setting the Height

Setting the height of the thicknessing table is easy and simple, the travel up/ down is 230 mm

Mitre Cross-cut fence

In both directions 2 x 45Ā° mitre cross cut fence are standard features on the machine.

Cross-cut table

The cross-cut table, supported by the telescopic arm, is equipped with a sturdy cross-cut fence with 2 flip stops, thus enabling large workpieces to be machined.

Optional Extra Support table

Extra support table for sliding table

single phase combination woodworking machine | MWM
Safety Hood

Safety hood for tenoning with diameter capacity of 260 mm

NXZ Panel Saw Scoring Unit
Scoring Unit

Scoring unit for the 250 mm version

Spindle

4-speed spindle arbor with speeds 2900 / 4000 / 6000 / 7500

Spindle Diameter

Standard spindle diameter is 30mm, the working length is 120mm, the up and down stroke is 140 mm
