Sawyer HB-800H Heavy Duty Resaw

From £21,500.00 + VAT

(£25,800.00 inc VAT)

SAWYER HB-800H Vertical Band Resaw

  • Cast iron dynamically balanced wheels
  • No pit required
  • Hydraulic blade tension
  • Invertor controlled feed system with soft entry
  • Digital fence with motorised positioning
  • Automatic pressurised lubrication system with reservoir tank
  • External control panel
  • 30hp motor
  • Infeed and outfeed bed rollers
  • Tilting fence
Call our sales team 0116 2893469
Payment Options
  • Finance Options Available
  • Payment on Account/Invoice
  • Credit/Debit Card
Payment Options

Technical Specifications

Max material height
350mm
Saw blade width
40mm
Table height from floor
97mm
Max. distance from guide to table
370mm
Throat capacity
778mm
Dust extraction outlets
2x 100mm
Blade linear speed
28m/ sec
Packing dimensions
2530 x 850 x 1410mm
Saw wheel diameter
800mm (32″)
Table size
1150 x 800mm
table tilting
90° – 30°
Saw blade length
5485 – 5515mm
Saw blade width
24-41mm
Motor power
30HP
Net / Gross weight
665/880kg

Sawyer HB-800H Heavy Duty Resaw


SAWYER HB-800H Vertical Band Resaw

A heavy duty, modern resaw with impressive features:

  • Cast iron dynamicly balanced wheels
  • No pit required
  • Hydraulic blade tension
  • Invertor controlled feed system with soft entry
  • Digital fence with motorised positioning
  • Automatic pressurised lubrication system with reservoir tank
  • External control panel
  • 30hp motor
  • Infeed and outfeed bed rollers
  • Tilting fence
  • CE Spec
Hydraulic blade tension system

Position the blade on the wheel,simply turn the switch to engage the hydraulic tension system and correct pressure will be set every time..

Soft Entry

The invertor driven feed system senses the timber before the timber hits the blade. For the first 50mm of cutting, the feeder will run slow, protecting the blade from bending or shattering. After the first initial cut, the feed system increases the speed to the desired cut speed.

Digital Fence

Simply key in your cut size, the fence will move its self to the correct position with auto lock.

Automatic lucrication

Oil mist is delivered directly onto the saw blade via the pressurised oil reservoir
