Technical Specifications
USED Felder KF700S 2015 Combination Machine 3PH
Felder introduces the KF 700 saw-shaper, a ground breaking fusion of two high-end professional woodworking machines. This combination sets new standards in woodworking, thanks to its innovative design, proven Felder technology, and flawless component integration. Whether you’re in a workshop, commerce, or industrial setting, the KF 700 offers the ultimate solution to tackle any woodworking challenge.
The KF 700 is available in various models, including the KF 700 Professional series, with sliding table lengths ranging from 51 ⅛″ (1300 mm) to 98 ⅜″ (2500 mm), as well as outrigger tables in sizes of 43 ¼″ (1100 mm) and 51 ⅛″ (1300 mm). This versatility ensures ample space for smooth material feed and effortless processing of large-format workpieces. For those with the most demanding requirements and extensive work areas, this used Felder KF700S 2015 combination machine 3PH offers optional format sliding tables extending up to 98 ⅜″ (2500 mm) or 110 ¼″ (2800 mm), paired with a 126″ (3200 mm) outrigger table extending up to 59″ (1500 mm).
Experience premium operating comfort with the optional “Power-Drive” control system, which provides precise settings and exceptional repeatability. You can effortlessly adjust the height and angle of the saw blade and spindle with accuracy down to tenths of a millimetre, all monitored in real-time on the user-friendly LED display.
Quick Change Spindle System
X-Roll Precision Guiding System
Power-Drive – Circular Saw Blade
Saw Assembly
The FELDER circular saw unit “104” Manufactured entirely from cast iron, the new Felder “104” saw unit fulfils the highest demands of modern woodworking.
- 4″ (104 mm) cutting height with a 12 3/8″ (315 mm) saw blade diameter
- Electronic height adjustment of the saw blade (“Power-Drive” K1)
- Electrical height and angle adjustment of the saw unit with LED display (“Power-Drive” K2)
- Precise height adjustment via precision linear guides
- Optimal extraction with a completely enclosed saw aggregate
- Large scale, double ball bearing saw arbor
Easy Glide
The patented tilt segment “Easy-Glide” fulfils the highest requirements in businesses and industries. A precise, guided, double-sided support, guarantees maximum load bearing and tolerance free tilting and is absolutely maintenance free. A special, highly durable synthetic material situated in the guide of the tilting segment ensures extremely smooth movement and long-lasting precision. The tilting guide system, a synthetic material tried and tested in aerospace and lock construction, works without the requirement of lubrication and is totally resistant to dust. With a 6 year factory guarantee this Felder component offers reliability for many years to come.
Circular Saw Shaft
The electronically balanced saw Arbor with dual bearing seat system is powered via a Poly-V belt. Combined this results in an almost 100 % transmission of power to the saw blade. The saw Arbor diameter on our machinery is a standard European size of 30 mm (1,18″). We offer this size of Arbor for increased stability when performing a bigger cut and also more user safety when especially using dado tooling. The standard US size Arbor is 16 mm (5/8″). This is almost half the diameter of our Arbor and is intended for lighter machinery with small tooling.
Dado
The Felder 700 Series saw assembly is fully compatible with dado tooling. Thanks to removable flanges and table insert, the Felder designed, fully adjustable dado cutters can be used.
Power Drive
Similarly, the saw blade height and angle settings can be set to an accuracy of a tenth of a millimetre. For fine tuning there is also a push button and a clear LED display screen to show you the actual current value.
Scoring Unit
For chip free cutting of laminated panels. The saw blade can be mechanically or electronically driven and can be set in both height and lateral position.
X-Roll Precision Guiding System
The continuously developed linear guiding system from Felder has been astounding woodworkers since 1990. The high quality format sliding table guiding technology “X-Roll” comes with a 10 year Felder warranty and offers amazing operating smoothness and is completely maintenance free. The “x” design of the position of the roller bearings ensures that they move smoothly along hardened guides.
Shaper Fence “230”
The fence allows tooling of a maximum diameter of 230 mm to be used. The fine adjustment can be set between -5 to +25 mm. The extraction of the chips is done via the integrated extraction connection.
For a convenient option we can equip your Felder 700 Series machine with start buttons for the main and scoring blades.
The New Felder Overhead Saw guard
Highest operating safety and maximum flexibility when processing large dimensioned workpieces: the new Felder overhead saw guard can be swung away easily and is always there where it is required.
The Rip Fence
The rip capacity comes standard with 31” (800 mm) or optional 49” (1250 mm). The rip fence almost hovers over the table. The single handed quick clamping and fine adjustment systems ensure quick and accurate setting of the rip fence. The easy to read rip scale is perfectly integrated into the saw table. The aluminium rip fence plate can be adjusted forward and back to optimise the feed of work pieces. When working with narrow and thin cuts of wood or with the saw blade tilted, it can be inverted and used in the lying position.
Electronic Digital Display
The rip fence can be fitted with an electronic digital-display. The perfect integration of the electronic unit allows you to turn the display around 90°, so the values are clearly and exactly readable from the operating area. Additional functions such as the input of successive measurements make your daily working life easier.
Table Extension
Increase your working surface area as needed – Felder System Table Extensions Since their invention in 1969, Felder system table extensions have become a very common and useful choice for most Felder owners. Within seconds and without the use of tools you are able to increase the working surface of your Felder.
Spindle Moulder Unit
The Felder 700 Series spindle aggregate sets standards that are unparalleled.
- 115 mm spindle useable height above the table (140/160 mm)
- Quick-change system of the moulder spindle
- Change the speed simply from the front of the machine
- Highspeed spindle for router tools with a speed of 15,000 rpm
- Electrical height adjustment with digital LED display
- Electrical angle adjustment with digital LED display
- 4 operating speeds (3500, 6500, 8000, 10,000 rpm)
- Rearward tilt 0° to 45°
- Precise, double sided guide support
- Dovetail guidance system of the height adjustment
- Excellent vibration absorption from heavy cast iron unit
Tennoning and slotting
Large dimensioned and designed for maximum load bearing capacity, the aluminium format sliding table “hovers” on the “X-Roll”, a highly developed guiding technology. The X shape (“X-Roll”) design of the rollers distributes the load optimally on all sides. The linear surface of the steel rollers running on the hardened and ground guiding surface guarantees unbeatable precision and smoothness. “X-Roll” will warrant you the quality and precision that you expect from your new tilting spindle shaper. Another reason to choose Felder: 10 year factory warranty to underline the reliability of “X-Roll”.
Quick Change Spindle System
Advantages of the Felder spindle quick change system on this used Felder KF700S 2015 combination machine 3PH:
- Quick, easy change between different types of spindles
- Ability to use 30, 32, 35, 40, 50 mm and 1¼” diameter spindles
- Use of the Felder high speed router spindle for router bits or high speed tools at 15,000 rpm.
- Automatic repeatable setting for series production work
Table opening
The large table opening allows for maximum operator safety. With large dimensioned tenoning and panel raising tooling, the cutter block can be conveniently positioned below the table.
Tilt Bracket
The Felder device for tilting the feeder away means the power feeder always remains on the machine and can be used at any moment without problems.
Felder KF700S Features
Precision Mitre Index System
No reading errors due to the vernier scale. No more time wasted due to arduous approximations of angle values. The advantage of the Felder degree index is that the stop is set and fixed with-out losing time or making reading errors. Highly precise index positions allow for the accurate production of polygons like 5.625º (32 sided), 11.25º (16 sided) and 22.5º (8 sided). In addition, index positions at 15º, 20º, 25º, 30º, 35º, 40º and 45º can be used when working with the fence in both the fore and aft positions on the outrigger. Every index position is equipped with a length compensator and individual fine adjustment. This highly precise Felder degree index system is adjusted at the factory. This cost effective index system integrates well into the machine design and will increase your productivity.
Crosscut fence Stops
On request: the digital cross-cut stop. For repeatable accuracy to .001” with large LED display.
Outrigger table with floor support roller
- For rip and formatting cuts of large panel material
- Floor guides are height adjustable, 15 ft. (4.5 m) total length, consisting of 3 segments
