Technical Specifications
Phase
3ph
Max. Sawblade Diameter
300mm
Max. Depth of cut at 90° – 45°
100mm – 70mm
Cutting Width
1270mm
Saw blade Bore
30mm
Scoring Blade Cutting Depth
4.5mm
Dimensions of Sliding table
2850 x 310mm
Dimensions Sawtable
940 x 510mm
Diameter extraction pipe
100mm
Motor Power
4HP
Scribe Unit
Yes
Scribe Blade Diameter
100mm
Cutting Length
2500mm
RPM Main Saw
4500 RPM
Scoring Blade Bore
20mm
Dimensions of table extension
720mm x 450mm
Dimension cross-cutting table
1060 x 510mm
Weight
550 KG
Adjustment scoring Unit
Fine adjustment of the scoring unit
Scoring Unit
Thickness with adjustable scoring blade ‘Leader’.
Mitre fence
The 2 x 45° mitre fence is equipped with a reversible stop and heavy duty woodclamp.
Overhead saw guard (Optional)
Optional Overhead saw guard
Parallel fence
Parallel fence with micro adjustment, alu profile can be lowered to the table for narrow cuts with tilted saw blade
Support table
Extra support table.
