Now Sold USED Robland T120-L Spindle Moulder

Enquire for price


This T120TLĀ  machine is NOT STANDARD SPEC

The following options are installed

  • Aigner spindle guard fences

If you would like the Aigner Fences removed we can subtractĀ Ā£600.00+VAT off the machine.

  • TL PACK – Table Extensions and Pull Out Support.Ā
  • 2018 Machine
  • 32mm Quick interchangeable spindleĀ
  • Comfort pack – fence is lifted and and lowered from the table with a swing away device, motorised rise & fall of Spindle Height, digital readout of height



Now Sold Call our sales team 0116 2893469
Payment Options
  • Finance Options Available
  • Payment on Account/Invoice
  • Credit/Debit Card
Payment Options

Technical Specifications

Voltage / phase
415V / 3phase
Weight
655 KG
Spindle Length
180 mm
Spindle Stroke
205 mm
Cast iron table dimensions
1200 x 705 mm
Table height
930 mm
Motor power
7.5 Kw / 9.5 HP
Shaft Diameter (fixed)
50mm
Shaft Diameter (Quick exchnage)
30 / 32 / 40 / 50 mm
Spindle Rotation Speed
3000 / 4500 / 6000 / 7000 / 10000 RPM
Max. Diameter and height table opening
320 x 95 mm
Dust Extraction outlet
120 mm

NEED ASSISTANCE OR EXPERT ADVICE?

We pride ourselves in offering a friendly and professional service

Interchangeable MK 5 shaft

Diameter upon request 30/40/50 mm.

Robland T120-S Spindle Moulder stable fence | MW Machinery
Sturdy, Stable fence

Sturdy, stable fence with micro adjustment and positioning by handwheel and mechanical indicators.

Linear Guides

The fence moves on linear guides (PRO PACK)

Read-out Height

Handwheel with integrated analogue read-out height for spindle moulder (PRO PACK)

5 Rotation Speeds

The machine is equipped with 5 different rotation speeds as standard (3,000/4,500/6,000/7,000 and 10,000)

Swing Away Device

Fence is lifted and lowered from the table with a swing away device (COMFORT PACK)

Motorised rise and fall and digital read-out

Motorised rise and fall, and digital read-out of spindle height. (COMFORT PACK)

Cast Iron tenoning table with fence

Cast iron tenoning table with fence. It’s also possible to place the guide in an angle. There’s also a wood clamp on the plate.

Extendible front panel support

Extendible front panel support

The Integral Fence Aigner

The integral fence aigner makes sure you can work precise and safe. The fence is easy to use without any tools. You can also regulate the height.

The Aluminium spindle guard fence

This aluminium spindle guard fence is strong and steady. At the opening of the spindle, there are wooden blocks, to protect the guard if the knives would kick in.

The ring guard fence

The ring guard fence is ideal to make pieces with different bow shapes. by using a mold, it’s possible to shape the wood by gliding against the ring guard all around the spindle.
