Compacto Fox 80 Turbo Briquetting Press

Compacto

From £54,500.00 + VAT

(£65,400.00 inc VAT)

The huge KG per hour output of this machine is achived by using 2 hydraulic pumps and a water cooled hydrualic system. Producing a briquette every 2 seconds.

Call our sales team 0116 2893469
Payment Options
  • Finance Options Available
  • Payment on Account/Invoice
  • Credit/Debit Card
Payment Options

Technical Specifications

Made in
Germany
Throughput
350-550 Kg/hr
Machine Weight
1500 KG
Emissions DB
74
Model
Fox 80 Turbo
Briquette Diameter
80mm
Motor Pump
75 Litre hydrualic pre-compression
Overall dimensions
L2095 x W1300 x H1700 mm

Compacto Fox 80 Turbo Briquetting Press

The huge KG per hour output of this machine is achived by using 2 hydraulic pumps and a water cooled hydrualic system. Producing a briquette every 2 seconds.

The Fox briquetting presses are able to manufacture materials like wood shavings, sawdust, wood chips, dust and other residual materials into stable, cylindrical briquettes. Compared to loose material, the initial volume will be reduced by up to 90%.

Residual materials transformed into compact briquettes can be used energetically much more efficiently and sold profitable.

A further advantage based on briquetting is the reduction in the danger of fires and explosions. Because of the fact that briquettes are considered as low-flammable like solid wood there aren’t any additional costs for complex fire protection regulations.

The material moisture content shouldn’t exceed a maximum of 18% ATRO. Furthermore the granule size has to be smaller then 20 mm.

By changing individual parameters, the briquetting presses can be adapted to customer materials, required throughput performances and individual conditions. It’s possible to choose from various cylinder sizes, drive engine variants and silo shapes. The filling of the briquetting press can take place manually or automatically.

During the material flow via a screw, a belt conveyor or a suction unit, the machine recognizes the fill level of the silo and is able to start and stop automatically.

There is no operating personnel necessary. The produced briquettes can be transported with a briquette transport pipe to the briquette stock without any further use of energy, just by pressure of the hydraulic. Function: Shavings are fed in the hopper, where it is dosed and supplied by an integrated agitator into the pre-compression unit. In this unit runs a hydraulic piston, which pre-compresses the material and feeds the main cylinder.

The hydraulic piston presses the material into the closed sleeve until the adjusted pressure is reached (which is usually set up to 80 bars). Then the sleeve opens and finally a stable briquette is produced. The more homogeneous the material, the more uniform results the length of the produced briquettes.

Tech Specs


  • Briquette diameter: 80 mm
  • Output (depending on Material): 350 – 550 kg/h
  • Motor: 27.5 kW
  • Length: 2095 mm
  • Width: 1300 mm
  • Height: 1700 mm
  • Weight: 1500 kg
  • Oil tank: 220 Litre
  • Hopper Diameter: 1000 mm
  • Hopper Content: appr. 1.0 qbm
  • Pump: 75 Litre hydraulic pre-compression
