Technical Specifications
Make
Maggi
SAW BLADE DIAMETER (MM)
400mm
SAW BLADE TILT RANGE
0 – 45
MOTOR POWER
4hp
TABLE SIZE
1580 x 975mm
MAX CUTTING WIDTH
545mm
GROSS WEIGHT
215kg
Model
Junior 640
BLADE BORE DIAMETER
30mm
BLADE SPEED
2800rpm
DUST HOOD OUTLET DIAMETER
1 x 60mm + 1 x 100mm
MAX CUTTING HEIGHT
125mm
DEPTH OF CUT AT 45°
80mm
NET WEIGHT
203kg
PACKING DIMENSIONS
1600 x 850 x 660mm
All Maggi machines we sell are CE approved, complying with all current regulations.
This includes a braked motor, enclosed blade and two dust extraction ports. The chassis of the machine has been designed with an anti-noise system arm and base made of cast-iron. The blade moves on 4 carriage bearings and is retracted with a return spring.
The junior 640 can accept a 400mm diameter blade allowing a 125mm depth of cut at 2800 rpm. Powered by a 4hp motor and with the ability to angle and turn the blade. This machine is a grea addition to any worshop.
This machine is avaliable in 1ph or 3ph.
Articulated Arm and Head Unit
For diagonal cuts
Inclined cuts and trimmings
(Optional) Laser Pointer and assembly
