Robland SD410 Planer Thicknesser SPIRAL BLOCK

£7,500.00 +VAT From £6,950.00 +VAT

(£8,340.00 inc VAT)

Installed on this machine are the following options

    • Comfort Pack

Electrical rise & fall of the thicknessing bed

    • Spiral Cutter Block

instead of standard block

    • 7kW motor

instead of standard 4.4kW motor

Call our sales team 0116 2893469
Payment Options
  • Finance Options Available
  • Payment on Account/Invoice
  • Credit/Debit Card
Payment Options

Technical Specifications

Motor Power
6.6HP
cutterblock speed
5500 rpm
length of outfeed table
980mm
max thicknessing height
250mm
Dust extraction outlet
120mm
fence dimensions
1360 x 200mm
Cutterblock diameter
90mm
Length of infeed table
1020mm
tilting fence
90° – 45°
max planing width
410mm
voltage / phase
415V / 3ph only

Digital System


On the machine not equipped with a comfort pack, the position of the thicknesser table is indicated with a mechanical digital system, the fine adjustment of the height of the thicknesser table is being done with the handwheel.

Friction Reduction Rolls


2 friction reduction rolls: easier sliding of wet wood.

Tersa


The machine can be equipped with a Tersa system, to achieve a fast exchange of the knives.

Need assistance or Expert Advice?

We pride ourselves in offering a friendly and professional service

4 Sturdy Columns


The thicknesser table is based on to 4 sturdy columns.

Thickness Capacity


Maximal thickness capacity is 250 mm.

Cast-Iron Sections


Cast-iron sections for the bearing of the in-and outfeed rollers and planer shaft.

Planer Fence


Adjustable planer fence, tilting between 45° and 90°

Heavy Hinges


Heavy hinges and strong springs for smooth and easy opening of the table.

Comfort Pack


The SD 410 a comfort pack option is equipped with a digital read out, 2 feeding speeds (6 and 12 m/min), a 6,6 HP motor, an automatic star-delta, and a table extension on the thicknesser table.

Table Extension (not on this machine)


The table extension on the thicknesser table in the comfort pack.

Spiral cutterblock


Auxiliary Fence
