Robland Z400 EL Digital Pack Options available

Original price was: £12,500.00.Current price is: £9,000.00.

(£10,800.00 inc VAT)

OPTIONS FITTED

  • 1 Digital Readout on Flipper Stop
  • Digital Readout on the Parallel Rip Fence
  • Electronic rise, fall and tilt of main blade
  • 7kW motor / 9.5HP
  • Digital read out of angle
  • Safe LED scribe light fitted.

The Z-Series offers you a broad selection of saw diameters (300, 400 or 500 mm), sliding tables, outrigger tables, options and accessories, to be combined with one of four different executions : manual (M), electrical height and tilt of the blade (EL), controlled parallel fence (X1) or a 3 axes controlled machine (X3). The saw aggregate is made out of one piece in cast iron for natural absorption of vibrations and therefor offers superior stability and precision.

Call our sales team 0116 2893469
Payment Options
  • Finance Options Available
  • Payment on Account/Invoice
  • Credit/Debit Card
Payment Options

Technical Specifications

Sliding Table Length
3200 mm
Motor Power
7 kW / 9 HP
Blade Diameter
400 mm
Saw Blade tilt range
90Ā° – 45Ā°
Max blade projection at 45Ā°
90 mm
Speed scoring blade
8200 RPM
Cutting length
3200 mm
Sliding Table width
395 mm
Parallel / RIP fence cut width
1350 mm
Voltage / Phase
415V / 3ph
Saw Blade rpm
3000 / 4000 / 5000
max. blade projection at 90Ā°
125 mm
Motor Scoring Unit
1.3 kW
Scoring blade diameter
120 x 20 mm
Dust extraction outlet
1 x 120 mm + 1 x 100 mm

Markfield Woodworking Machinery ltd have been an Authorised Robland UK dealer for over 20 years and are the UKā€™s largest stockist of Robland machinery


Roblandā€™s biggest selling Panel Saw with electronic blade rise/fall/ tilt

Our Robland machines come with a 12 month manufactures warranty. In stock now.

The Robland Z400 continues on from the successes of the Z3200 that has been our bestselling sliding panel saw for the past 20 years, one of the reasons is the sawā€™s simple no nonsense design, separate motors for main blade and scribe. Manual raise and fall of the saw height and angle. Easy adjustment of the scribe blade, solid manual rip fence running on a solid 50mm bar. Fantastic industrial panel saw offering excellent value for money with a heavy duty European build.

The new Z400 EL spec includes machines quadrants for the arbour tilt, a better cross cut fence / stops and larger motors. Electric blade rise / fall / tilt with digital readouts.

Outrigger Table

Large outrigger table with telescopic cross cut fence, index system and digital read out on flippers.

Saw Aggregate

Saw aggregate rotating on shells maintaining the origin while tilting.

Sliding Table

The hard anodized sliding table is precision machined. The heart of the sliding table is 8 hardened steel rods inserted into the table extrusion, thus making the whole system extremely wear free.

Saw Guard

Overhead Saw guard with integrated tube for improved Extraction.

Cast Iron Saw Aggregate

Saw aggregate in cast for more precision and stability.

Without Scoring Blade

400mm without scoring blade.

With Scoring Blade

300mm with scoring blade.

Control Panel

Control panel Z400EL with analogue indication of the Height & tilt of the blade.

*This machine is equipped with just the tilt indication option*

Digital Read-out

Digital read-out on parallel fence.
