Technical Specifications
Capacity
3500 m3/h
Vacuum Velocity
30 m/sec
Filter Sizes
Q160 x 1030 mm
Waste Storage
1 Pc metal Container
Motor Drive Type
Direct Type
Weight
300 kg
Motor Power
3 Kw 4 hp | 3,000 RPM
Filter Quantity
15 Pcs
Filtration Area
7.75 m2
Vacuum Diameter
Q200 mm
Unit Sizes
730*1730*2280 mm
Electrical Panel
Star-Delta-Starter
- Mobile dust extractor with a flow capacity of 3500 m3 Per hour
- Body sheet thickness is 1.2mm. The propeller and blades are at least 3mm according to the fan size. The propeller is dynamically and statically balanced.
- Painted in two colours with electrostatic
- In Ip55 Standards, IE3 high efficiency motor is used. There is a part of the separator that protects the propeller against balancing and reduces the risk of fire
- The part separator prevents parts larger than 25x25mm from entering the propeller. This will protect the propeller against balancing and ensures longevity
- Metal Propeller
- CE Certified
